2014 FICEP MDL: 1102DZTT CNC AUTOMATIC DRILLING & THERMAL COPING LINE
S/N:29301• FICEP ARIANNA CNC CONTROL •DRILLING: I BEAM WEB HEIGHT: 3.14"-43.9"• I- BEAM FLANGE WIDTH: 1.65", 17.7" • UNP CHANNELS WEB HEIGHT: 3.14"-43.9" • UNP CHANNELS FLANGE WIDTH: 1.77"-11.8" • ANGLES MIN 3.14" X 3.14" X 5/16" THICK • ANGLES MAX 9,8" X 9.8" X 1.5" THICK • SQUARE TUBES MIN 3.1" X 3.1"-MAX 17.7" X 17.7" • RECTANGULAR TUBES MIN 3.1" X 1.5"-MAX 43.3" X 17.7" • MAX THICKNESS DRILLING:1.96" • MAX LENGTH:68'
6 POSITION ATC • MAX HOLE DIA:1.5" • 50 TAPER SPINDLE • SPINDLE: 180-2,500 RPM • MAX LINEAR WEIGHT: 147LB PER FOOT • 65' INFEED & 75' OUTFEED CONVEYOR • THERMAL DYNAMICS MAX 200 PLASMA POWER SUPPLY • DONALDSON DUST COLLECTOR (NEW 2005/REBUILT 2014).
**NO TRANSFER CONVEYOR TO BE SOLD W UNIT**
